Non-Stroking AutoDrill Units provide standard high-precision ground spindles. They are available with different spindle options. They can hold many different drilling, reaming and tapping attachments.

High precision ground spindle: Standard
Versatile spindle options – Multiple nose options:

  • ER8
  • ER11
  • ER16
  • ER20
  • ER25
  • ER32
  • ER40
  • ER50
  • Key-Type Chuck – 0.500” Capacity
  • Key-Type Chuck – 0.750” Capacity
  • J2 Jacobs Taper
  • J33 Jacobs Taper
  • J3 Jacobs Taper
  • J5 Jacobs Taper
  • 1/2-20 External Threads
  • 5/8-16 External Threads
  • Internal Threads (choose)
  • MT1 Morse Taper
  • MT2 Morse Taper
  • MT3 Morse Taper
  • MT4 Morse Taper
  • MT5 Morse Taper
  • MT6 Morse Taper
  • MT7 Morse Taper
  • Custom: Let us know what you want!

Spindle thru-holes for introduction of media, coolant, etc.

We can thread the rear of our spindles to allow rotary union adaption.

  • Series 1000 – 2.125” C-C or greater (53.975 MM)
  • Series 2000 – 3.000” C-C or greater (76.2 MM)
  • Series 5000 – 4.400” C-C or greater (111.76 MM)
  • Custom – We can build smaller (or larger) units for you. Just let us know…

Suitable for use with linear tables:

  • ER8
  • ER11
  • ER16
  • ER20
  • ER25
  • ER32
  • ER40
  • ER50
  • Ask us – We can do custom builds!

If you do not see what you want, please contact us! We can probably do it…
